How to build Video amplifier 1
August 8, 2010 - category: VideoPart List
- R1= 15Kohm+15Kohm
- R2-3-4= 10Kohm
- R5.....9= 1Kohm
- R10= 820ohm
- R11= 1Mohm
- R12= 100ohm trimmer
- R13-15= 47ohm
- R14= 10Kohm
- C1= 10uF 63V MKT
- C2-4= 100nF 63V
- C3=4.7pF ceramic
- IC1= LH0032
- S1= 1X2 mini switch
- S2= 1X6 sel.
- J1-2= BNC connector
Circuit diagrams
circuit from http://users.otenet.gr/~athsam/video_amplifier_1.htm
